Hemispheric Q25

  • Integrated DVR (up To 64 GB) For Long-term Recording Without Network Load
  • Digital Continuous Tilting, Panning And Zooming Without Mechanically Moving The Camera
  • Robust And Low Maintenance With No Moving Parts
  • Newest MOBOTIX 5MP Sensor Technology With Up To 30 Fps And Improved Zoom
  • Microphone, Speaker, MxBus And Intelligent Movement Sensors (MxActivitySensor)
  • Optimized Image Quality And Reduced Motion Blur Even In Poor Lighting Conditions
ModelsBasic, Sec, Sec-Night
LensesL12 (180° x 160°)
L25 (82° x 61°)
SensitivityColor: 0.25 lux (t=1/60 s), 0.013 lux (t=1/1 s)
B/W: 0.05 lux (t=1/60 s), 0.0025 lux (t=1/1 s)
MxLEO - Lowlight Exposure Optimization
Sensors1/2.5" CMOS, 5 Megapixel, progressive scan
Max. image sizeColor + B/W: 2048 x 1536 (QXGA)
Image formatFree image format selection (from 160 x 120 to 2048 x 1536);
PTZ view, Quad view, panorama broad view image, double panoramic view, panorama focus with 3 views
Max. frame rate (M-JPEG)VGA: 30 fps, MEGA/HD: 10 fps,QXGA: 4 fps(Live/Recording)
Max. Video stream (MxPEG)VGA: 30 fps, MEGA/HD: 30 fps, QXGA: 20 fps(Live/Recording/Audio)
Image compressionMxPEG, M-JPEG, JPG, H.264 (SIP Video only)
Internal DVRMicroSD slot (camera internal video recording up to 64 GB; 4 GB card pre-installed)
External storageDirectly on NAS and PC/Server without additional recording software
Software (free of charge)Video-Management-Software MxEasy,
Control room software MxControlCenter, MOBOTIX App for iOS devices from iOS 5.0
Image processingBacklight compensation, automatic white balance, image
distortion correction (panoramic image correction included), motion detection, MxActivitySensor
Virtual PTZDigital Pan/Tilt/Zoom, continuous 8x zoom, full image recording in the background
Alarm/EventsTriggering of events by integrated multiple-window motion detection, external signal,
temperature sensor, notification over email, FTP, IP-Telephony (VoIP, SIP), visual/acoustic alarm Pre- and post-alarm images
NetworkIntegrated microphone and speaker, lip-synchronous audio, two-way speaker, audio recording
InterfacesEthernet 10/100, IPv4/IPv6, MiniUSB, MxBus, IO and RS232 via MX-232-IO-Box (accessory)
Video phone telephonyVoIP, SIP, two-way speaker, remote control via DTMF signaling, event notification
SecurityUser-/Group management, HTTPS/SSL, IP address filter, IEEE 802.1x, Intrusion Detection, digital image signature
CertificatesEMC (EN 55022, CISPR 22, EN 55024, EN 61000-6-1/2, FCC part15B, CFR 47, AS/NZS 3548)
Power SupplyPower over Ethernet (PoE acc. IEEE 802.3af), PoE class variable (2/3) according to operating mode; power consumption typ. 4.5 W
Operating conditionsIP65 (DIN EN 60529), -30° bis +50 °C (-22°F to +122°F)
DimensionsØ x H: 16 x 5 cm
Weightapprox. 450 g
